Cardiac Science AED G3 Pro Operation and Service Manual
CAUTION Federal law restricts this device to be sold by or on the order of a physician or practitioner licensed by state law in which he/she practices to use or order the use of the device.
IMPORTANT Read this Operation and Service Manual carefully. It contains information about your safety and the safety of others. Become familiar with the controls and how to use the AED properly before operating the product.
Cardiac Science AEDs are manufactured by: Corporate Headquarters: Cardiac Science, Inc. 1900 Main Street, Suite 700 Irvine, CA 92614 USA Web site: www.cardiacscience.com E-mail: info@cardiacscience.com Manufacturing: Cardiac Science, Inc. 5474 Feltl Road Minnetonka, MN 55343-7982 USA Authorized European Representative: Cardiac Science International Kirke Vaerloesevej 14 3500 Vaerloese DENMARK
TRADEMARK INFORMATION FirstSave, Powerheart, MasterTrak, MDLink, STAR, IntelliSense, RescueReady, RescueLink, RHYTHMx and Survivalink are trademarks and registered trademarks of Cardiac Science, Inc. Microsoft and Windows are registered trademarks of Microsoft Corporation. All other trademarks are the property of their respective owners.
PATENTS This device may be covered by the following U.S. and foreign patents: 5,792,190, 5,999,493, 5,402,884, 5,579,919, 5,749,902, 5,645,571, 6,029,085, 5,984,102, 5,919,212, 5,891,172, 5,674,266, 5,700,281, 5,891,173, 5,968,080, 6,263,239, 5,797,969, D402,758, D405,754, 5,909,138, 6,173,203, 6,088,616, 5,897,576, 5,955,956, 6,083,246, 6,064,909, 6,038,473, 5,868,794, 6,115,638, 6,366,809, 5,474,574, 6,246,907, 6,289,243, 6,411,846, 6,480,734, EP00756878 Other U.S. and foreign patents pending.
© 2004-2005 Cardiac Science, Inc. All rights reserved.
112-2034-001 Rev F
page 3
LIMITED WARRANTY The Cardiac Science AED Operation and Service Manual and any and all information contained herein do not constitute any warranty as to the Powerheart AED G3 Pro, or any related products in any manner whatsoever. The “Limited Warranty” is shipped with the AED and serves as the sole and exclusive warranty provided by Cardiac Science regarding Cardiac Science AED products.
ORDER ENTRY To order additional Cardiac Science AEDs or accessories: Worldwide (800) 991-5465 (949) 797-3806 (949) 851-4418 (Fax) aedorders@cardiacscience.com
CUSTOMER SERVICE To receive 24-hour customer support: U.S. and Canada (888) 466-8686 (949) 797-3807 (949) 851-4425 (Fax) aedsupport@cardiacscience.com
Outside U.S. and Canada + 44 161 926 0000 + 44 161 926 0002 (Fax)
UK + 44 161 926 0000 + 44 161 926 0002 (Fax) aed@cardiacscience.co.uk
There is no charge to the customer for a customer support call. Please have the serial and model numbers available when contacting Customer Service. (The serial and model numbers are located on the underside of the Cardiac Science AED.)
NOTICE OF RIGHTS All rights reserved. No part of this documentation may be reproduced or transmitted in any form by any means without the express written permission of Cardiac Science, Inc. Information in this documentation is subject to change without notice. Names and data used in the examples are fictitious unless otherwise noted.
DEFIBRILLATOR TRACKING Defibrillator manufacturers and distributors are required, under the Safe Medical Devices Act of 1990, to track the location of defibrillators they sell. Please notify Cardiac Science Customer Service in the event that your defibrillator is sold, donated, lost, stolen, exported, destroyed or if it was not purchased directly from Cardiac Science, Inc.
page 4
112-2034-001 Rev F
© 2004-2005 Cardiac Science, Inc. All rights reserved.
Cardiac Science AED G3 Pro Operation and Service Manual
TABLE OF CONTENTS SECTION 1 - SAFETY OVERVIEW...7 SAFETY TERMS DEFINITIONS...7 SAFETY ALERT DESCRIPTIONS ...8 SYMBOL DESCRIPTIONS ...11
SECTION 2 - INTRODUCTION OVERVIEW...15 AED DESCRIPTION ...15 INDICATIONS FOR USE ...15 RHYTHMx AED ECG ANALYSIS ALGORITHM...16 RESCUE PROTOCOL...18 STAR BIPHASIC WAVEFORM ...18 STAR BIPHASIC ENERGY PROTOCOLS FOR POWERHEART AED G3 PRO ...18 OPERATOR TRAINING REQUIREMENTS ...20
SECTION 3 - GETTING STARTED OVERVIEW...21 UNPACKING AND INSPECTING ...21 AED PARTS...22 AED MODES ...23 POWERHEART AED G3 PRO BATTERIES ...24 DEFIBRILLATION PADS (ELECTRODES)...28 AED INDICATORS ...29 SETTING THE AED INTERNAL CLOCK ...33 VOICE PROMPTS AND TEXT DISPLAY...33
SECTION 4 - INSTRUCTIONS FOR USE OVERVIEW...37 OPERATING MODES...37 STEP 1: ASSESSMENT AND PAD PLACEMENT...38 STEP 2: ECG ANALYSIS (AED MODE) ...39 STEP 3: SHOCK DELIVERY AND CPR MODE (AED MODE)...40 STEP 4: POST RESCUE ...41 USING MANUAL OVERRIDE (MANUAL MODE)...41 ECG DISPLAY FOR ONGOING MONITORING (ECG MONITORING MODE) ...42 Z-BAR INDICATOR...43 WARNINGS...44
© 2004-2005 Cardiac Science, Inc. All rights reserved.
112-2034-001 Rev F
page 5
SECTION 5 - DATA MANAGEMENT OVERVIEW...45 RECORDING RESCUE DATA ...45 REVIEWING RESCUE DATA ...45 MULTIPLE RESCUE FUNCTIONALITY...46
SECTION 6 - MAINTENANCE & TROUBLESHOOTING OVERVIEW...47 SELF-TESTS...47 INDICATOR TROUBLESHOOTING TABLE...48 SCHEDULED MAINTENANCE...49 AUTHORIZED REPAIR SERVICE ...50 FREQUENTLY ASKED QUESTIONS ...51
SECTION 7 - TECHNICAL DATA OVERVIEW...53 PARAMETERS...53 SAFETY AND PERFORMANCE STANDARDS...56 STAR BIPHASIC WAVEFORM...59 RHYTHMx ECG ANALYSIS PERFORMANCE ...61
page 6
112-2034-001 Rev F
© 2004-2005 Cardiac Science, Inc. All rights reserved.
Section 1 - Safety
SECTION 1 – SAFETY OVERVIEW This section presents safety information to guard against injury to persons and damage to the Powerheart AED G3 Pro. TOPIC Safety Terms Definitions Safety Alert Descriptions Symbol Descriptions
PAGE # 7 8 11
SAFETY TERMS DEFINITIONS BEFORE OPERATING THE POWERHEART AED G3 PRO Become familiar with the various safety alerts in this section. Safety alerts identify potential hazards using symbols and words to explain what could potentially harm you, the patient, or the Powerheart AED G3 Pro.
SAFETY TERMS AND DEFINITIONS The triangle attention symbol shown below, left, identifies the potential hazard categories. The definition of each category is as follows:
DANGER: This alert identifies hazards that will cause serious personal injury or death. WARNING: This alert identifies hazards that may cause serious personal injury or death. CAUTION: This alert identifies hazards that may cause minor personal injury, product damage, or property damage.
PRODUCT REFERENCES For purposes of retaining simple, clear instructions in this manual, note the product references used. Features, specifications, operating instructions and maintenance on the Powerheart AED G3 Pro will be referred to as “AED” or “device”. Defibrillation electrodes will be referred to as “defibrillation pads” or “pads”, ECG monitoring electrodes will be referred to as “ECG monitoring electrodes” or “ECG electrodes”. Features and specifications vary, so please read this manual carefully. For questions regarding the differing features among Cardiac Science AEDs, please contact Customer Service at (888) 466-8686 in the U.S. and Canada and +44 161 926 0000 outside the U.S. and Canada. © 2004-2005 Cardiac Science, Inc. All rights reserved.
112-2034-001 Rev F
page 7
SAFETY ALERT DESCRIPTIONS The following is a list of Cardiac Science AED safety alerts that appear in this section and throughout this manual. You must read, understand, and heed these safety alerts before attempting to operate the AED.
DANGER: Fire and Explosion Hazard Exercise caution when operating the AED close to flammable gases (including concentrated oxygen) to avoid possible explosion or fire hazard. WARNING: Shock Hazard Defibrillation shock current flowing through unwanted pathways is potentially a serious electrical shock hazard. To avoid this hazard during defibrillation abide by all of the following: • Do not touch the patient, unless performance of CPR is indicated • Do not touch metal objects in contact with the patient • Keep defibrillation pads and ECG electrodes clear of other electrodes or metal parts in contact with patient • Disconnect all non-defibrillator proof equipment from the patient before defibrillation WARNING: Shock and Possible Equipment Damage Disconnect all non-defibrillator proof equipment from the patient before defibrillation to prevent electrical shock and potential damage to the equipment. WARNING: Battery (P/N: 9145) is NOT Rechargeable Do not attempt to recharge the battery. Any attempt to recharge the battery may result in an explosion or fire hazard. Only battery (P/N: 9144) is rechargeable. WARNING: Shock Hazard Do not disassemble the AED! Failure to observe this warning can result in personal injury or death. Refer maintenance issues to Cardiac Science authorized service personnel. WARNING: Battery Serviceability Do not disassemble the battery! Failure to observe this warning can result in personal injury or death. Refer maintenance issues to authorized service personnel. CAUTION: Temperature Extremes Exposing the AED to extreme environmental conditions outside of its operating parameters may compromise the ability of the AED to function properly. The RescueReady® daily self-test verifies the impact of extreme environmental conditions on the AED; if the daily self-test determines environmental conditions outside of the AED’s operating parameters, a “SERVICE REQUIRED” alert will be issued to prompt the user to move the AED to environmental conditions within the acceptable operating parameters at once. See Section 7 – Technical Data, Parameters, Operation and Standby Conditions on page 54. CAUTION: Lithium Sulfur Dioxide Battery Pressurized contents: Never recharge, short circuit, puncture, deform, or expose to temperatures above 65°C (149°F). Remove the battery when discharged. page 8
112-2034-001 Rev F
© 2004-2005 Cardiac Science, Inc. All rights reserved.
Section 1 - Safety
CAUTION: Lithium-ion Battery Never short circuit, puncture, deform, or expose to temperatures above 65°C (149°F). CAUTION: Battery Disposal Recycle or dispose of the lithium battery in accordance with all federal, state and local laws. To avoid fire and explosion hazard, do not burn or incinerate the battery. CAUTION: Use only Approved Equipment The Rechargeable battery is made solely for Powerheart AED G3 Pro, and is NOT to be used with any other AED models. Using batteries, pads, cables, or optional equipment other than those approved by the manufacturer may cause the AED to function improperly during a rescue. CAUTION: Possible Improper AED Performance Using defibrillation pads that are damaged or expired may result in improper AED performance. CAUTION: Possible Radio Frequency (RF) Susceptibility RF susceptibility from cellular phones, CB radios and FM 2-way radio may cause incorrect rhythm recognition and subsequent shock advisory. When attempting a rescue using the AED, do not operate wireless radiotelephones within 2 meters of the AED – turn power OFF to the radiotelephone and other like equipment near the incident. CAUTION: Possible Interference with Implanted Pacemaker Therapy should not be delayed for patients with implanted pacemakers and a defibrillation attempt should be made if the patient is unconscious and not breathing. The AED has pacemaker detection and rejection, however with some pacemakers the AED may not advise a defibrillation shock.1 Placing Defibrillation Pads: • Do not place the defibrillation pads directly over an implanted device. • Place the defibrillation pads at least one inch from any implanted device.
CAUTION: Moving the Patient During a Rescue During a rescue attempt, excessive jostling or moving of the patient may cause AEDs to improperly analyze the patient’s cardiac rhythm. Stop all motion or vibration before attempting a rescue. CAUTION: Case Cleaning Solutions When disinfecting the case, use a non-oxidizing disinfectant, such as ammonium salts or a glutaraldehyde based cleaning solution, to avoid damage to the metal connectors.
1
Cummins, R., ed., Advanced Cardiac Life Support; AHA (1994): Ch. 4.
© 2004-2005 Cardiac Science, Inc. All rights reserved.
112-2034-001 Rev F
page 9
page 10
112-2034-001 Rev F
© 2004-2005 Cardiac Science, Inc. All rights reserved.
Section 1 - Safety
SYMBOL DESCRIPTIONS The following symbols may appear in this manual, on the AED, or on its optional components. Some of the symbols represent standards and compliances associated with the AED and its use.
Dangerous Voltage: The defibrillator output has high voltage and can present a shock hazard. Please read and understand all safety alerts in this manual before attempting to operate the AED. Attention!: Identifies important information in this manual, on the AED, or on its component parts regarding the safe and proper use of the AED. Defibrillator Proof Type BF Equipment: The AED, when connected to the patient’s chest by the defibrillation pads, can withstand the effects of an externally applied defibrillation shock. CE Mark: This equipment conforms to essential requirements of the Medical Device Directive 93/42/EEC.
IP24
The AED is protected against the effects of splashing water in accordance with IEC 60529. Classified by ETL Semko with respect to electric shock, fire and mechanical hazards only in accordance with UL 60601-1, CAN/CSA C22.2 No.601.1-M90, EN60601-1 and EN60601-2-4. Conforms to UL Standard UL60601-1. Certified to CAN/CSA Standard C22.2 No. 601.1-M90. International symbol for ON. Open the lid to turn on the AED.
Open the lid to turn ON the AED.
Indicates the AED battery status. The illuminated areas indicate the remaining battery capacity.
1. Position of defibrillation pads on the chest of patient. 2. When pads on screen are flashing, check defibrillation pads. The defibrillation pads are missing, not connected or have compromised functionality.
Indicates AED requires maintenance by authorized service personnel. When the SHOCK indicator is lit, push this button to deliver a defibrillation shock. When pushed and confirmed, activates manual mode.
© 2004-2005 Cardiac Science, Inc. All rights reserved.
112-2034-001 Rev F
page 11
SYMBOL DESCRIPTIONS (CONT.) The Z-Bar provides a relative visual indicator of the total transthoracic impedance between the two defibrillation pads. A red indicator with a BLACK X means the AED requires operator attention or maintenance, and is not RescueReady. This symbol will be referred to as RED in the remainder of this manual. A green indicator without a BLACK X means the AED is RescueReady. This symbol will be referred to as GREEN in the remainder of this manual. Use defibrillation pads by this date.
Date of manufacture, year and month.
Latex free. Disposable. Single patient use only. Tear here to open. Do not recharge battery. For use by or on the order of a Physician, or persons licensed by state law. Dispose of properly in accordance with all state, province, and country regulations. Do not incinerate or expose to open flame. Explosion Hazard: Do not use in the presence of a flammable gas, including concentrated oxygen.
Upper and lower temperature limits.
Device model number, battery model number. Lot number Default start-up screen.
page 12
112-2034-001 Rev F
© 2004-2005 Cardiac Science, Inc. All rights reserved.
Section 1 - Safety
Lithium sulfur dioxide Additional information is provided in the AED Operation and Service Manual. Points to important information regarding the use of the AED. Lift here
Manufacturer
Authorized European Representative
Indicates placement of ECG leads and electrodes, AHA.
Indicates placement of ECG leads and electrodes, IEC.
Indicates that the Manual Override function has been disabled.
C-UL US Classification Mark: indicates compliance with US and Canadian safety requirements.
GS Mark: indicates compliance with German safety requirements. Lithium Ion
Rechargeable Battery Charge LED: Solid yellow indicates battery charging, blinking yellow indicates charging error. Battery Capacity: Indicates the AED battery status. The illuminated areas indicate the remaining battery capacity when the test button is pressed. Test Button: Push to view battery capacity
© 2004-2005 Cardiac Science, Inc. All rights reserved.
112-2034-001 Rev F
page 13
page 14
112-2034-001 Rev F
© 2004-2005 Cardiac Science, Inc. All rights reserved.
Section 2 - Introduction
SECTION 2 – INTRODUCTION OVERVIEW This section presents information about the AED, its use, and the training requirements for operation. Topic AED Description Indications for Use RHYTHMx AED ECG Analysis Algorithm Rescue Protocol STAR Biphasic Waveform STAR Biphasic Energy Protocols for Powerheart AED Operator Training Requirements
Page # 15 15 16 18 18 18 20
AED DESCRIPTION The AED is a self-testing, battery-operated automated external defibrillator (AED). After applying the AED’s defibrillation pads to the patient’s chest, the AED automatically analyzes the patient’s electrocardiogram (ECG) and advises the operator to push the button and deliver a shock if needed. The AED guides the operator through the rescue using a combination of voice prompts, audible alerts, and visible indicators. At the discretion of Advanced Life Support (ALS) personnel, the AED can be converted to manual override mode, and deliver a shock by pushing the SHOCK button. The AED can also provide non-diagnostic ECG monitoring.
INDICATIONS FOR USE The AED with STAR Biphasic Waveform is intended to be used by personnel who have been trained in its operation. The operator should be qualified by training in basic life support, CPR/AED or other physician-authorized emergency medical response. The device is indicated for emergency treatment of victims exhibiting symptoms of sudden cardiac arrest who are unresponsive and not breathing. If the victim is breathing post-resuscitation, the AED should be left attached to allow for acquisition and detection of the ECG rhythm. If a shockable ventricular tachyarrhythmia recurs, the device will charge automatically and advise the operator to deliver therapy; or when in manual override mode, ALS personnel will monitor the ECG display and deliver a shock by pushing the shock button to deliver therapy. When the patient is a child under 8 years of age or weighs less than 55 lbs (25kg), the AED should be used with the Model 9730 Pediatric Attenuated Defibrillation Electrodes. Therapy should not be delayed to determine the patient’s exact age or weight.
© 2004-2005 Cardiac Science, Inc. All rights reserved.
112-2034-001 Rev F
page 15
RHYTHMx® AED ECG ANALYSIS ALGORITHM The RHYTHMx AED ECG analysis algorithm provides ECG detection capabilities, The features available with the AED include the following: • Detection Rate • Asystole Threshold • Noise Detection • Non-Committed Shock • Synchronized Shock • Pacemaker Pulse Rejection • SVT Discriminators • Supraventricular Tachycardia (SVT) Rate • Continuous Monitoring
DETECTION RATE All ventricular fibrillation (VF) and ventricular tachycardia (VT) rhythms at or above this rate will be classified as shockable. All rhythms below this rate will be classified as non-shockable. This rate is programmable between 120 bpm (beats per minute) and 240 bpm via MDLink Software by the Medical Director. The default Detection Rate is 160 bpm.
ASYSTOLE THRESHOLD The asystole peak-to-peak threshold is set at 0.08 mV. ECG rhythms at or below 0.08 mV will be classified as asystole and will not be shockable.
NOISE DETECTION The AED will detect noise artifact in the ECG. Noise could be introduced by excessive moving of the patient or electronic noise from external sources like cellular and radiotelephones. When noise is detected, the AED will issue the prompt “ANALYSIS INTERRUPTED. STOP PATIENT MOTION ” to warn the operator. The AED will then proceed to reanalyze the rhythm and continue with the rescue.
NON-COMMITTED SHOCK After the AED advises a shock, it continues to monitor the patient ECG rhythm. If the patient’s rhythm changes to a non-shockable rhythm before the actual shock is delivered, the AED will advise that the rhythm has changed and issue the prompt “RHYTHM CHANGED. SHOCK CANCELLED.” The AED will override the charge and continue ECG analysis.
page 16
112-2034-001 Rev F
© 2004-2005 Cardiac Science, Inc. All rights reserved.
Section 2 - Introduction
SYNCHRONIZED SHOCK The AED is designed to synchronize shock delivery on the R-wave. The AED will automatically attempt to synchronize to the R-wave. If delivery cannot be synchronized within one second, a non-synchronized shock will be delivered.
PACEMAKER PULSE DETECTION The AED contains pacemaker pulse detection circuitry to detect pulses from an implanted pacemaker.
SVT DISCRIMINATORS The AED is supplied with the SVT Discriminator enabled and with the default setting “NO THERAPY FOR SVT”. With the factory default setting of “NO THERAPY FOR SVT”, the AED will not shock an SVT rhythm. SVT Discriminators are sophisticated filters that analyze the morphology of the ECG waveforms and distinguish VF/VT from SVT and Normal Sinus Rhythms (NSR). The SVT Discriminator will only be applied to rhythms that fall between the Detection Rate and the SVT Rate. The factory default setting for this feature is “NO THERAPY FOR SVT”, however the Medical Director can enable this feature using MDLink on the AED.
SVT RATE All rhythms with rates between the Detection Rate and SVT Rate will be screened through a number of SVT Discriminators to classify them into VF/VT or SVT. Rhythms classified as SVT between the two set rates are not shockable. All SVT rhythms above the rates will be classified as shockable. The SVT Rate must be greater than the Detection Rate and is selectable between 160 and 300 bpm or, “NO THERAPY FOR SVT” can be selected via MDLink Software by the Medical Director on the AED.
MONITORING DURING CPR Cardiac Science AEDs are supplied with the Monitoring during CPR disabled. This is the factory default setting. The AED can monitor the ECG rhythms continuously throughout the rescue including during Charge and CPR mode. Monitoring during CPR will interrupt CPR if a shockable rhythm is detected. When CPR is interrupted, the prompt, “DO NOT TOUCH PATIENT. ANALYZING RHYTHM” will be issued. If the analysis shows the rhythm to be non-shockable, continuous monitoring will be disabled for the remainder of the rescue. Only one false interruption will be allowed during a single rescue cycle. CPR mode will not be interrupted if preceded by three consecutive shocks. The factory default setting for Monitoring during CPR in CPR is disabled, however the Medical Director can enable/disable this feature via MDLink software.
© 2004-2005 Cardiac Science, Inc. All rights reserved.
112-2034-001 Rev F
page 17
RESCUE PROTOCOL The AED rescue protocol is consistent with the guidelines recommended by the American Heart Association (AHA)1 and the International Liaison Committee on Resuscitation (ILCOR). Upon detecting a shockable cardiac rhythm, the AED advises the operator to press the SHOCK button to deliver a series of up to 3 defibrillation shocks followed by performing 1 minute of CPR. The 3 defibrillation shocks are delivered in a pre-programmed sequence.
Note: The CPR protocol can be modified, for example from 1 to 3 minutes, in increments of 5 seconds, so CPR may be administered if the first analysis is non-shockable or following two consecutive non-shockable analysis decisions.
STAR BIPHASIC WAVEFORM The STAR Biphasic Waveform is designed to measure the patient’s impedance and deliver a customized shock. This allows the delivery of an optimized energy level to each patient. The energy levels for the AED are available in three different defibrillation shock2 configurations. See table on next page and page 59 for additional information.
STAR BIPHASIC ENERGY PROTOCOLS FOR POWERHEART AED G3 PRO Cardiac Science’s patented STAR® Biphasic defibrillation waveform will deliver variable escalating energy that is customized to each patient’s needs based upon a patient’s thoracic impedance. This customization adjusts for the unique physical differences between patients. The range of impedance over which the device will deliver a shock is 25-180 Ohms. The AED comes equipped with five different FDA cleared biphasic energy protocols. The operator, with guidance, direction and implementation from its designated AED program Medical Director, may select from one of these five protocols when placing the AED into service. The AED’s factory default energy protocol is 200-300-300 Joule (J) escalating Variable Energy (VE). The first shock is delivered within the range of 140J-250J (200J nominal). Subsequent shocks are delivered within a range of 190J-360J (300J nominal). See next page.
1 “Guidelines 2000 for Cardiopulmonary Resuscitation and Emergency Cardiovascular Care” American Heart Association; 2000. Suppl. Circulation 102(8). August 22, 2000
2
The ultra-low current, low current and high current shocks are variable energy. The actual energy is determined by the patient’s impedance.
page 18
112-2034-001 Rev F
© 2004-2005 Cardiac Science, Inc. All rights reserved.
Section 2 - Introduction
These protocols are selected by using our MDLink software program. The five biphasic energy protocols available are as follows:
1
Energy Protocols
Shock Sequence
Energy Level
Energy Range (J)
Factory Default
1. 2. 3.
200VE 300VE 300VE
140J-250J 190J-360J 190J-360J
Protocol #2
1. 2. 3.
200VE 200VE 300VE
140J-250J 140J-250J 190J-360J
Protocol #3
1. 2. 3.
150VE 200VE 200VE
105J-195J 140J-250J 140J-250J
Protocol #4
1. 2. 3.
150VE 150VE 200VE
105J-195J 105J-195J 140J-250J
Protocol #5
1. 2. 3.
200VE 200VE 200VE
140J-250J 140J-250J 140J-250J
1
The ultra-low current, low current and high current shocks are variable energy. The actual energy is determined by the patient’s impedance.
© 2004-2005 Cardiac Science, Inc. All rights reserved.
112-2034-001 Rev F
page 19
OPERATOR TRAINING REQUIREMENTS Persons authorized to operate the AED must have all of the following minimum training: • • • •
Defibrillation training and other training as required by state, province, or country regulations. Training on operation and use of the AED. Additional training as required by the physician or Medical Director. A thorough understanding of the procedures in this manual.
Notes: Keep valid certificates of training and certification as required by state, province, or country regulations.
page 20
112-2034-001 Rev F
© 2004-2005 Cardiac Science, Inc. All rights reserved.
